Stainless steel ferrule fitting and compression pipe fitting

Ferrule fittings is also known as a compression fitting, is a type of tubing or pipe connection that uses a compression mechanism to create a leak-tight seal between two or more components. It is commonly used in fluid systems, such as plumbing, hydraulic and pneumatic systems, and in various industries including manufacturing, oil and gas, and chemical processing.

The ferrule fitting consists of the following parts: a nut, a front ferrule, and a back ferrule;

A popular length span of ferrule fittings is between 1/16″ to 2″ for proportional lengths and between 2 to 50 mm for measured lengths.

Main products: 304 316L Stainless steel tee, cross, coupling, thread coupling, elbow etc.

The nut is typically made of metal and has internal threads that allow it to be tightened onto another threaded component, such as a valve or a fitting. The front and back ferrules are usually made of softer materials like brass, stainless steel, or plastic.

During installation, the tubing or pipe is inserted into the ferrule fitting, and the nut is tightened. As the nut is tightened, the front ferrule is forced against the tubing, while the back ferrule is pushed radially inward.This creates a strong mechanical grip on the tubing. Simultaneously, the front ferrule forms a seal against the fitting or valve, preventing leak.

Stainless steel ferrule fittings advantage:

Possess firm connection, high pressure resistance, tightness and repeated installation, simple and convenient installation and maintenance, safe and reliable work

Good for fire prevention, crack prevention, high-altitude operation and can eliminate the disadvantages caused by careless welding, no welding is needed

Finely ground with a special process , the hand feel is glossy and delicate, the interior is cleanly and bright, and the ruler can be accurately controlled

Ferrule type installation is environmental protection and reusable, easy to operate, convenient and free to disassemble, break the traditional installation method

Suitable for hard tube conversion hose and need to penetrate the wall and board occasion.

As a professional manufacturer and supplier, we provide high-quality products. If you are interested in our products or have any questions, please feel free to contact us.
